Waterproof Wire to Wire MC4 Solar PV Cable Connector for 4 sq mm and 6 sq mm wires

Easily connect and disconnect connectors which are waterproof

Product Code 7234

Available We dispatch same day if ordered by 1PM (excluding holidays), then courier usually takes 2-5 days.
Waterproof Wire to Wire MC4 Solar PV Cable Connector for 4 sq mm and 6 sq mm wires
Sunrom Product Code for Ordering:
7234

High-Quality MC4 Connectors Male-Female Pair with pins.

These connectors are suitable for crimping on to 4 sq mm and 6 sq mm cables.

MC4 connectors are single-contact electric connectors commonly used for connecting solar panels. MC4 stands for the manufacturer Multi-contact and a 4 sq mm contact assembly pin. MC4s allow strings of panels to be easily constructed by pushing the connectors from adjacent panels together by hand, but require a tool to disconnect them to ensure that they do not accidentally disconnect when the cables are pulled.

25 Years of Life.

Contact material: copper, tin-plated.

MC4 connector pair for solar applications.

Weather-resistant. UV protected. Lasts for years.

Technical Data of MC4 solar cable connector:

Rated current: 30A of MC4 solar cable connector  Degree of protection: IP2*/IP67

Rated voltage: 1500V DC(IEC) of MC4 solar cable connector  Flame class: UL94-V0

Test voltage:6000V(50Hz,1min) of MC4 solar cable connector  Safety class: II of MC4 solar cable connector

Overvoltage category:CATIII of MC4 solar cable connector  Suitable class: OD4.5-7.0(2.5-6.0mm²)

The contact resistance of plug connector: 0.5mΩ  Insertion force/withdrawal force: ≤50N/≥50N

Contact material: Copper, TIN Plated  Connecting System: Crimp connection

Insulation material: PPO of MC4 solar cable connector  Temperature range: -40~+90(IEC)



FAQs:

1. How to connect connectors?

The wire needs to be crimped at the ends provided for the purpose, and then it clicks into its place. Then the threaded back cover to be put on. This gives a weatherproof joint. The male to a female connector is a click on the type of simple assembly.



2. What is the current-carrying capacity or ampacity of these mc4 connectors?

30 AMPS



3. Is this suitable for 10 sq mm wire?

No. For 10 sq mm wire, you will need high capacity MC4. This is suitable for 4 and 6 sq mm wires.



4. What is MC4 and where it can be used?

MC4 stands for the manufacturer Multi-Contact and the 4 for the 4 mm diameter contact pin. Solar MC4 connectors are used for secure DC connection from solar panels to the inverter, charge controller, VFD, etc



5. Are these connectors waterproof?

Yes, it has IP67 which means waterproof, Weather resistant. Also, it is UV protected.



Internal View
