SMA Female PCB Vertical Mount - SMA-KE
Useful for mounting in PCB to connect external RF antenna, Gold Plated, PCB Mount
Downloads
5465 Dimensions
SMA Female PCB Vertical Mount - SMA-KE
Sunrom Product Code for Ordering:
5465
SMA series rf connector has small volume, wide frequency band, excellent mechanical properties, high reliability and so on. It is one of the most popular used RF coaxial connectors.
|
Temperature Range |
-55~+155°C (PE Cable -40~+85°C) |
|
|
Impedance |
50Ω |
|
|
Vibration |
98m/S2 (10~2000Hz), 10g |
|
|
Frequency Range |
DC-12.4GHz(semi-rigid cable DC-18 GHz) |
|
|
Insertion Loss |
≤ 0.15dB/6GHz |
|
|
Withstanding Voltage |
1000V r.m.s at sea level |
|
|
Working Voltage |
335Vr.m.s at sea level |
|
|
Insulation Resistance |
≥ 5000 MΩ |
|
|
Durability |
≥ 500(cycles) |
|
|
Contact resistance: |
CenterContact ≤ 3mΩ |
|
|
Outer Contact ≤ 2.5mΩ |
||
